Metric Male 74 Degree Cone Fitting/Sea O-Ring Boss L-Series ISO 11926-3 (1QO, 1QO-RN)

Name: Metric Male 74 Degree Cone Fitting/Sea O-Ring Boss L-Series ISO 11926-3 (1QO, 1QO-RN)
Rating: 5 (99 reviews)

Product Description
hydraulic adaptor metric male O-Ring flat sealing pipe fittings

Material: Carbon Steel, Stainless Steel
Surface Treatment: White or Yellow Zinc-Plated
Standards: Eaton, DIN, ISO, SAE, JIC or As customers' drawing
Export Markets: Global

Get A Quote

PREV：Reducer Tube Adaptor with Swivel Nut
পরবর্তী：পরবর্তী নিবন্ধ নেই

Specification
Contact Us

Standard:	DIN
Material:	Medium Carbon Steel
Connection:	Female
Surface Treatment:	Galvanized Sheet
Head Type:	Round
Manufacturer:	Factory

PART NO.	THREAD E	THREAD F	TUBE O.D. D1	DIMENSIONS B	DIMENSIONS l1	DIMENSIONS L1	DIMENSIONS S1	DIMENSIONS S2
PART NO.	THREAD E	THREAD F	TUBE O.D. D1	DIMENSIONS B	DIMENSIONS l1	DIMENSIONS L1	DIMENSIONS S1	DIMENSIONS S2
1CM-12-10WD	M12X1.5	M10X1	6	8	8.5	23	14	14	31.5L
1CM-14-12WD	M14X1.5	M12X1.5	8	12	10	25	17	17
1CM-16-12WD	M16X1.5	M12X1.5	10	12	11	25	17	19
1CM-16-14WD	M16X1.5	M14X1.5	10	12	11	26	19	19
1CM-16-18WD	M16X1.5	M18X1.5	10	12	12.5	27	24	19
1CM-18-16WD	M18X1.5	M16X1.5	12	12	12.5	27	22	22
1CM-18WD	M18X1.5	M18X1.5	12	12	12.5	27	24	22
1CM-18-22WD	M18X1.5	M22X1.5	12	14	14	29	27	22
1CM-22-18WD	M22X1.5	M18X1.5	15	12	13.5	29	24	27
1CM-22WD	M22X1.5	M22X1.5	15	14	15	30	27	27
1CM-26-22WD	M26X1.5	M22X1.5	18	14	14.5	31	27	32
1CM-30-26WD	M30X2	M26X1.5	22	16	16.5	33	32	36	16L
1CM-30-27WD	M30X2	M27X2	22	16	16.5	33	32	36
1CM-36-33WD	M36X2	M33X2	28	18	17.5	34	41	41
1CM-45-42WD	M45X2	M42X2	35	20	17.5	39	50	50
1CM-52-48WD	M52X2	M48X2	42	22	19	42	55	60
1DM-14-12WD	M14X1.5	M12X1.5	6	12	13	28	17	17	63S
1DM-16-14WD	M16X1.5	M14X1.5	8	12	15	30	19	19
1DM-18-16WD	M18X1.5	M16X1.5	10	12	15	31	22	22
1DM-20-18WD	M20X1.5	M18X1.5	12	12	17	33	24	24
1DM-22-20WD	M22X1.5	M20X1.5	14	14	19	37	27	27
1DM-24-22WD	M24X1.5	M22X1.5	16	14	18.5	37	27	30	40S
1DM-30-27WD	M30X2	M27X2	20	16	20.5	42	32	36
1DM-36-33WD	M36X2	M33X2	25	18	23	47	41	46
1DM-42WD	M42X2	M42X2	30	20	23.5	50	50	50
1DM-52-48WD	M52X2	M48X2	38	22	26	57	55	60	31.5S
Note: In case if you are interested to order the adapter in complete set with cutting ring and nut ,it is necessary to insert suffix "RN" after our part no.,for example 1DM-20-18WD/RN.

About OPK Fitting

OPK FITTING Hydraulic Equipment Factory is a specialized domestic factory with hydraulic pipes and adaptors production experience. Our managing scope relates to various fields such as hydraulic systems etc.; Including all kinds of materials with different pressure levels, flexible hydraulic hoses with various size criteria, hose fitting, adaptor, etc. They have been respectively applied in the hydraulic and fluid conveyance systems of industries, such as machinery, metallurgy petroleum, construction, ships, space-flight, agriculture, pharmaceutical, food, and so forth.
Ningbo OPK Fitting Co., Ltd. is a China professional Metric Male 74 Degree Cone Fitting/Sea O-Ring Boss L-Series ISO 11926-3 (1QO, 1QO-RN) manufacturers and ODM & OEM Metric Male 74 Degree Cone Fitting/Sea O-Ring Boss L-Series ISO 11926-3 (1QO, 1QO-RN) factory .We can provide custom-made stainless steel hydraulic fittings, hydraulic hose crimp fittings, and hydraulic quick couplings.

Over 10 years of experience.

A team of skilled design professionals and talent.

Excellent product quality and thoughtful customer service.

Our 10 years of customisation experience has created the OPK Fitting brand value.
